Technical Specifications - Turnkey Specialists Inc. 4mm scfd dehy skid:
• Performance Target: Reduces water content down to standard pipeline quality (typically < 7 lbs of H₂O/MMSCF or down to 3 lbs/MMSCF if specified).
• Contactor Column Size: 16-inch outer diameter (OD) x25’.
• Reboiler Thermal Duty: rated at 0.5 MMBtu/hr.

Two-Stage Process Flow - used TSI 4mm scfd dehy skid for sale:
Absorption Loop
• Inlet Scrubber:
• Contactor
• Dry Gas Exit
Regeneration / Stripping Loop
• Flash Separator.
• Filters
• Reboiler & Still Column
• Recirculation

Key Mechanical Equipment — buy this used TSI 4mm scfd dehy skid:
• Modular Skid
• Glycol Circulation Pump
• Burner Management System (BMS
• Control Panel: Equips the site operator with a local PLC interface for digital control of flow rates, pressure variations, and automated valve sequences.

Contact Jeff for more details, to inspect, and or discuss pricing.
